Sunricher 4-канальный фазовый диммер DALI

Compatible Load Types

Load Type

Maximum Load

Remarks

Due to variety of LED lamp

Dimmable LED lamps

1*200W @ 110V, 1*400W @ 230V

2*150W @ 110V, 2*300W @ 230V

3*125W @ 110V, 3*250W @ 230V

4*100W @ 110V, 4*200W @ 230V

designs, maximum number of LED lamps per channel is further dependent on power

factor result when connected to dimmer.

Dimmable LED drivers

1*200W @ 110V, 1*400W @ 230V

2*150W @ 110V, 2*300W @ 230V

3*125W @ 110V, 3*250W @ 230V

4*100W @ 110V, 4*200W @ 230V

Maximum permitted number of drivers per channel is 200W/400W divided by driver nameplate power rating.

Incandescent lighting, Halogen 240V lamps

1*400W @ 110V, 1*800W @ 230V

2*300W @ 110V, 2*600W @ 230V

3*250W @ 110V, 3*500W @ 230V

4*200W @ 110V, 4*400W @ 230V

Low voltage halogen

lighting with electronic transformers

1*200W @ 110V, 1*400W @ 230V

2*150W @ 110V, 2*300W @ 230V

3*125W @ 110V, 3*250W @ 230V

4*100W @ 110V, 4*200W @ 230V
